Size Matrix
Measurements are in millimeters and inches, rounded off). This is a guide only and we always recommend that you calculate all measurements manually before ordering.
Our friendly team are always happy to go through all available options. Just give us a call: 0151 525 3398
“Access space” refers to the gap once the doors have been moved to one side.
Top Tips
- Include overlaps in your calculations. We always recommend an overlap of at least 50mm.
- Optimal width for 2 x 950mm doors: (950mm x 2 = 1900mm) – 50mm overlap = 1850mm.
- Optimal width for 4 x 650mm doors: (650mm x 4 = 2600mm) – 150mm (3 overlaps at 50mm each) = 2450mm.
- When choosing between having two or three doors, we recommend two. Two or four doors will always result in having more access space.
| Combination 1 Recommended | Combination 2 | ||||||
|---|---|---|---|---|---|---|---|
| Size of Opening mm | inches |
Access space | Door 650mm 25.6″ | Door 950mm 37.4″ | Door combination preview | Access space | Door 650mm 25.6″ | Door 950mm 37.4″ |
| 1100mm | 43" | 450mm | 2 | • |
|
|||
| 1150mm | 45" | 500mm | 2 | • | ||||
| 1200mm | 47" | 550mm | 2 | • | ||||
| 1250mm | 49" | 600mm | 2 | • | ||||
| 1300mm | 51" | *Reduce width to 1250mm | ||||||
| 1350mm | 53" | *Reduce width to 1250mm | ||||||
| 1400mm | 55" | *Reduce width to 1250mm | ||||||
| 1450mm | 57" | 500mm | 1 | 1 |
|
|||
| 1500mm | 59" | 550mm | 1 | 1 | ||||
| 1550mm | 61" | 600mm | 1 | 1 | ||||
| 1600mm | 63" | 650mm | • | 2 |
|
|||
| 1650mm | 65" | 700mm | • | 2 | ||||
| 1700mm | 67" | 750mm | • | 2 | ||||
| 1750mm | 69" | 800mm | • | 2 | ||||
| 1800mm | 71" | 850mm | • | 2 | ||||
| 1850mm | 73" | 900mm | • | 2 | 550mm | 3 | • | |
| 1900mm | 75" | *Reduce width to 1850mm | 600mm | 3 | • | |||
| 1950mm | 77" | *Reduce width to 1850mm | 650mm | 4 | • | |||
| 2000mm | 79" | *Reduce width to 1850mm | 700mm | 4 | • | |||
| 2050mm | 81" | 750mm | 4 | • |
|
750mm | 2 | 1 |
| 2100mm | 83" | 850mm | 4 | • | 850mm | 2 | 1 | |
| 2150mm | 85" | 800mm | 4 | • | 850mm | 2 | 1 | |
| 2200mm | 87" | 900mm | 4 | • |
|
|||
| 2250mm | 89" | 950mm | 4 | • | ||||
| 2300mm | 91" | 1000mm | 4 | • | ||||
| 2350mm | 93" | 1050mm | 4 | • | ||||
| 2400mm | 94" | 1100mm | 4 | • | ||||
| 2450mm | 96" | 1150mm | 4 | • | ||||
| 2500mm | 98" | *Reduce width to 2450mm | 900mm | 2 | 2 | |||
| 2550mm | 100" | *Reduce width to 2450mm | 950mm | 2 | 2 | |||
| 2600mm | 102" | *Reduce width to 2450mm | 1000mm | 2 | 2 | |||
| 2650mm | 104" | 1050mm | 2 | 2 |
|
750mm | • | 3 |
| 2700mm | 106" | 1100mm | 2 | 2 | 800mm | • | 3 | |
| 2750mm | 108" | 1150mm | 2 | 2 | 850mm | • | 3 | |
| 2800mm | 110" | 1200mm | 2 | 2 |
|
|||
| 2850mm | 112" | 1250mm | 2 | 2 | ||||
| 2900mm | 114" | 1300mm | 2 | 2 | ||||
| 2950mm | 116" | 1350mm | 2 | 2 | ||||
| 3000mm | 118" | 1400mm | 2 | 2 | ||||
| 3050mm | 120" | 1450mm | 2 | 2 | ||||
| 3100mm | 122" | 1200mm | • | 4 |
|
1150mm | 6 | • |
| 3150mm | 124" | 1250mm | • | 4 | 1200mm | 6 | • | |
| 3200mm | 126" | 1300mm | • | 4 | 1250mm | 6 | • | |
| 3250mm | 128" | 1350mm | • | 4 | 1300mm | 6 | • | |
| 3300mm | 130" | 1400mm | • | 4 | 1350mm | 6 | • | |
| 3350mm | 132" | 1450mm | • | 4 | 1400mm | 6 | • | |
| 3400mm | 134" | 1500mm | • | 4 | 1450mm | 6 | • | |
| 3450mm | 136" | 1550mm | • | 4 | 1500mm | 6 | • | |
| 3500mm | 138" | 1600mm | • | 4 | 1550mm | 6 | • | |
| 3550mm | 140" | 1650mm | • | 4 | 1600mm | 6 | • | |
| 3600mm | 142" | 1700mm | • | 4 | 1650mm | 6 | • | |
| 3650mm | 144" | 1750mm | • | 4 | 1700mm | 6 | • | |
| 3700mm | 146" | 1800mm | • | 4 | 1750mm | 6 | • | |
| 3750mm | 148" | *Reduce width to 3650mm | 1500mm | 2 | 3 | |||
| 3800mm | 150" | *Reduce width to 3650mm | 1550mm | 2 | 3 | |||
| 3850mm | 152" | 1600mm | 2 | 3 |
|
1250mm | ||
| 3900mm | 154" | 1650mm | 2 | 3 | 1300mm | |||
| 3950mm | 156" | 1700mm | 2 | 3 | 1350mm | |||
| 4000mm | 158" | 1750mm | 2 | 3 | 1400mm | |||
*In some situations, there is no perfect solution for your available opening width. The wrong combination can result in a limited access space when trying to reach your wardrobe. It is therefore recommended to reduce the opening width by making use of side panels on either one or both sides of your available space.
Download instruction guide in PDF
View Step-by-step Guide
It is also very important to line up the Track & Rail from inside the wardrobe, for best results. Please see the red line as a reference, on the image below.
